Lenze EPM-T211

Permanent wiring

• Clearly structured labelling and diagnostics concept • 2-part concept: base module and electronic module

• The electronics can be replaced during maintenance work without

touching the wiring

• Bright LEDs are easy to see, even in poorly illuminated control

cabinets

• One LED and one labelling field is clearly assigned to each channel • The item designation remains on the base module

• Codes prevent the incorrect module type from being connected

Complies with the strictest requirements

The availability of EtherNet/IP-based bus systems lays the foundations

for new automation concepts in the field of machine and systems

engineering — the performance limits of established bus systems

are then eliminated.

The L-force I/O system 1000 offers highly deterministic control of

input and output modules, which also includes importing touch probe

inputs, such as those required for synchronised movements in clocked

production processes. A minimum internal cycle time, in combination

with a time stamp, ensures that the I/O system 1000 itself meets the

strictest speed requirements here. As such, it is also suitable for use

in realtime-based architectures.

At the very first glance, the system impresses with its slimline design,

as well as its clearly structured labelling and diagnostics concept. The

I/O modules, which offer space for 8 connections, require just

12.5 mm of space on the conventional DIN rail.

Compact structure User-oriented connection technique

The "internals" of the I/O system are also user friendly down to the

last detail: the I/O compound module, consisting of terminal block

• Slimline design

• 8 connection points in a width of just 12.5 mm

with backplane bus connection and electronics protected against • Tried-and-tested tension spring technology

polarity reversal, has a modular structure. This allows a defective • Stair-step shaped, space-saving wiring level

electronic module to changed when maintenance work needs to be • Consistent separation of electronics and the wiring level

performed without the wiring from the base module having to be • Up to 64 modules can be connected

disconnected. Service engineers know that this eliminates a common • Automatic connection via the backplane bus

source of errors – incorrect wiring. The stepped design of the connection level also offers advantages, including tension spring connection Performance and robustness

technology and permanent wiring, which has proven itself on • Gold-plated contacts guarantee a secure connection between the

modules standard terminals for years. For the wiring itself, a simple screwdriver

is sufficient. The simple and clear system of labelling and wiring for • Fault-tolerant protocols secure maximum availability – even in the

event of individual frame errors the new system also makes it a breeze to combine modules to create

complete stations. The integrated backplane bus allows up to • The large bandwidth of 48 MBits/s allows extremely fast response

times without telegram overheads 64 modules to be connected in any desired sequence by simply

plugging them in without the need for any wiring
