This document lists specifications for the NI PXIe-2790 solid
state power combiner and switch. All specifications are subject
to change without notice. Visit ni.com/manuals for the most
current specifications.
Refer to the NI Switches Help for detailed topology
information.
Caution To ensure the specified EMC
performance, operate this product only with
shielded cables and accessories.
Caution Refer to the Read Me First: Safety and
Electromagnetic Compatibility document at
ni.com/manuals for important safety and
compliance information.
Caution Using the NI PXIe-2790 in a manner not
described in this document may impair the
protection the NI PXIe-2790 provides.
About These Specifications
Specifications characterize the warranted performance of the
instrument under the following operating conditions:
• Chassis is powered on
• Calibration adjustment cycle maintained
• 50 Ω termination connected to unused I/O front panel
connectors
• Current product revision used
Specifications describe the warranted, traceable product
performance over ambient temperature ranges of 0 °C to 55 °C
unless otherwise noted.
Typical values describe useful product performance beyond
specifications that are not covered by warranty and do not
include guardbands for measurement uncertainty or drift.
Typical values may not be verified on all units shipped from
the factory. Unless otherwise noted, typical values cover the
expected performance of units over ambient temperature
ranges of 23 ±5 °C with a 90% confidence interval.
