NI 9234

The NI 9234 is a four-channel, high-accuracy dynamic signal acquisition module for making precise measurements from IEPE (Integrated Electronics Piezoelectric) sensors. It offers a wide

 dynamic range of 102 dB and incorporates integrated signal conditioning, making it suitable for a wide range of applications, including:

• Vibration measurement: The NI 9234 can be used to measure vibrations from accelerometers, which are commonly used to monitor the health of machinery and equipment.

• Sound measurement: The NI 9234 can also be used to measure sound pressure levels from microphones, which can be used for noise monitoring and acoustic analysis.

• Other IEPE sensor measurements: The NI 9234 can be used with a variety of other IEPE sensors, such as tachometers and proximity probes.

Key Features

• Four channels for simultaneous measurement of IEPE sensors

• 102 dB dynamic range for high-accuracy measurements

• Software-selectable AC/DC coupling for flexible measurements

• Integrated IEPE signal conditioning for simplified setup

• High-impedance input for low-noise measurements

• Compatible with NI CompactRIO and NI cDAQ systems

Benefits

• High-accuracy measurements: The NI 9234's wide dynamic range and high-impedance input ensure that you can capture even the smallest signals with precision.

• Flexible signal conditioning: The NI 9234's software-selectable AC/DC coupling allows you to easily configure the module for different types of measurements.

• Simplified setup: The NI 9234's integrated IEPE signal conditioning eliminates the need for external signal conditioning circuitry.

• Versatility: The NI 9234 can be used with a wide variety of IEPE sensors, making it a versatile tool for a wide range of applications.

Considerations

• Sensor compatibility: The NI 9234 is only compatible with IEPE sensors. If you need to measure signals from non-IEPE sensors, you will need to use a different data acquisition module.

• Signal conditioning: While the NI 9234 includes integrated IEPE signal conditioning, you may need to apply additional signal conditioning depending on the specific application.

• Sampling rate: The maximum sampling rate of the NI 9234 is 51.2 kS/s. If you need to sample at a higher rate, you will need to use a different data acquisition module.

Applications

• Vibration monitoring: The NI 9234 can be used to monitor the health of machinery and equipment by measuring vibrations. This can help to prevent breakdowns and improve safety.

• Noise monitoring: The NI 9234 can be used to measure noise levels in the environment. This can be used to identify noise sources and comply with noise regulations.

• Acoustic analysis: The NI 9234 can be used to analyze sound waves. This can be used for applications such as speech recognition and audio signal processing.

• Other IEPE sensor applications: The NI 9234 can be used with a variety of other IEPE sensors for a wide range of applications.

Conclusion

The NI 9234 is a versatile and powerful data acquisition module that is well-suited for a wide range of applications involving IEPE sensors. Its high accuracy, flexibility, and ease of use make

it an ideal choice for engineers and scientists who need to make precise measurements from IEPE sensors.
