Specifications are valid under the following conditions unless otherwise noted.
• Ambient temperature of Tcal
± 5 °C.
1
• Calibration interval of 1 year
• 30 minutes minutes warm-up time
• niDMM Digits Resolution property or NIDMM_ATTR_RESOLUTION_DIGITS
attribute set to 6.5
• niDMM Aperture Time Units property or NIDMM_ATTR_APERTURE_TIME_UNITS
attribute set to Power Line Cycles
• niDMM Aperture Time property or NIDMM_ATTR_APERTURE_TIME attribute set to 10
8 Specifications are for 4-wire measurements. For 2-wire measurements, perform offset nulling or
add 200 mΩ to specification. For relative humidity >80%, add 100 ppm/MΩ.
9 Relative to external calibration source. DMM must remain powered on.
10 Tcal
is the temperature at which last external calibration was performed. NI factory calibration is 23°C ±1°C.
11 2-wire resistance measurement only.
12 Can be used to test p-n junctions, LEDs, or zener diodes up to 10 V.
13 Tcal is the temperature at which last external calibration was performed. NI factory calibration is
23°C ±1 °C.
14 Use the 1 Year specification to calibrate on a 90-day cycle.
15 Tempco is the temperature coefficient. Tempco values are valid within the device's ambient
temperature range.
16 Applicable for non-sinewave signals up to the rated peak voltage, current, or bandwidth.
