OMRON R88D-WT04H

Compact 1/16 DIN Counters with Easy-to-UseFunctions, Four- or Six-Digit LCD DisplaysDesigned for easy operationHigh-speed response —5 K counts per secondPrescale function displaysin units of actual physicalparameters — length, volume, etc.(except A/SA types)H7CR-C and -SC provide large/small discrimination mode idealfor positioning and production controlEasy-to-read backlit LCD displayOn-line change of set value4-level key protectH7CR-S short 64 mm (2.52 in) body

Insulation resistance100 MΩ min. (at 500 VDC) (between current-carrying terminal and exposed non-current-carrying metalparts, and between non-continuous contacts)Dielectric strength2,000 VAC, 50/60 Hz for 1 min (between current-carrying terminal and exposed non-current-carryingmetal parts)Impulse voltageBetween power terminals: 1 kV for 24 or 12-24 VDC power supply, 3 kV for othersBetween current-carrying terminal and exposed non-current-carrying metal parts: 1.5kV for24 or 12-24 VDC power supply, 4.5 kV for others±2 kV between power terminals, ±600 V between input terminals (square-wave noise viaNoise immunitynoise simulator; pulse width: 1µs; 1-ns rise)Static immunityMalfunction: 8 kV; destruction: 15 kVVibrationMechanical durability: 10 to 55 Hz with 0.75-mm (0.03 in) single amplitude/55 to 150 Hz with 10 G 32Malfunction durability: 10 to 55 Hz with 0.5-mm (0.02 in) single amplitude/55 to 150 Hz with 10 G 32ShockMechanical durability: 30 GMalfunction durability: 10 GLifeMechanical: 10 million operations min.Electrical: 100,000 operations min. (at 3 A, 250 VAC general in use (p.f. = 0.7 to 0.8)WeightEconomical counters: AC types, approx. 230 g (8.1 oz.); DC types, approx. 150 g (5.3 oz.)Standard and +/– range counters: Approx. 170 g ( 6 oz.)

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
