3D53-18-1 3D53181 MAGNETEK

IMPORTANT: Programming is required to set up the drive for operation from externalterminals.

WARNING

Do not touch circuit components until main input power has been turned off and“CHARGE” lamp is extinguished. The capacitors are still charged and can bequite dangerous.

Do not connect or disconnect wires and connectors while power is applied to thecircuit.

CAUTION

Know your application before using either lnitialization function of Sn-03. Thisconstant must be set to 0000 for Drive mode operation.(See paragraph 2.25 foradditional information.)

1110 = Factory 2Wire Control lnitialization (Maintained RUN Contact)1111 = Factory 3-Wire Control lnitialization (Momentary START/STOP Contact)Entering either lnitialization code resets all constants EXCEPT Sn-01 AND Sn-02 tofactory settings, and automatically returns Sn-03 setting to 0000. lf the GPD 503 isconnected for 3-Wire control and this constant is set to 1110 (2-Wire Controllnitialization), the motor may run in reverse direction WITHOUT A RUN COMMANDAPPLIED.Equipment damage or personal injury may result.

IMPORTANT

Always ground the GPD 503 using ground terminal G ( E ). See paragraph 1.4.3.Grounding

Never connect main circuit output terminals T1, T2, and T3 to AC main circuit powersupply.

All constants have been factory set. Do not change their settings unnecessarily

Do not perform a “HIPOT" voltage test on any part of the GPD 503. Equipment uses semi.

conductors and is vulnerable to high voltage.

The Control PCB employs CMOS ICs which are easily damaged by static electricity. Useproper electrostatic discharge (ESD) procedures when handling the Control PCB.

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
