KEYENCE EX-V02P

Pressing the auto-zero (ZERO)

key sets the present voltage output

to 0 V (current output to 4 mA).

Zero-point adjustment with a

reference target can be completed

simply by pressing the ZERO key.

Type Cylindrical Threaded Cylindrical/Threaded

ø5.4 M10 ø14.5/M16 ø22/M12

Model

Sensor head EX-305 EX-110 EX-416 EX-422

Controller EX-201 EX-202 EX-205 EX-210

Measuring range 0 to 1 mm 0.04" 0 to 2 mm 0.08" 0 to 5 mm 0.20" 0 to 10 mm 0.39"

Analog

output

Output voltage 0 to 5 V (Output impedance 100 Ω)

Output current 4 to 20 mA (Applicable load: 0 to 350 Ω)

Resolution 0.04% of F.S. (Response frequency: LOW)

Linearity ±1% of F.S.

Response

frequency

HIGH 8 kHz (-3 dB) 1 ) 5 kHz (-3 dB 1 ) 3 kHz (-3 dB 1 ) 8 kHz (-3 dB

LOW 1.3 kHz (-3 dB)

Disconnection alarm output 2. NPN: 100 mA (40 V) max., Residual voltage: 1 V max. (N.C.)

Functions Auto-zero function/Response frequency selecting function

Temperature

fluctuation

Sensor head 1. .03% of F.S./ 0 °C

Controller 1. .04% of F.S./ 0 °C

Power supply voltage 12 to 24 VDC ±10%

Current consumption 240 mA max.

Ambient

temperature

Sensor head 10 to +60 -° 0 (14 to 14 C° g F), No freezin

Controller to +50 0° 2 (32 to 12 C° g F), No freezin

Relative humidity 35 to 85%, No condensation

Enclosure rating Sensor head: IP-67

Weight

Sensor head pprox. 45 g A g pprox. 55 A g pprox. 75 A g Approx. 200

Controller Approx. 285 g
