put bytes 4
Output bytes 0
Parameter bytes 6
Diagnostic bytes 20
Housing
Material PPE / PPE GF10
Mounting Profile rail 35 mm
Mechanical data
Dimensions (WxHxD) 12.9 mm x 109 mm x 76.5 mm
Net weight 59 g
Weight including accessories 59 g
Gross weight 74 g
Environmental conditions
Operating temperature 0 °C to 60 °C
Storage temperature -25 °C to 70 °C
Certifications
UL certification yes
KC certification yes
Type SM 031
Module ID 0401 15C3
General information
Note -
Features 2x AI
12 Bit
Voltage 0…10 V
Current consumption/power loss
Current consumption from backplane bus 80 mA
Power loss 0.7 W
Technical data analog inputs
Number of inputs 2
Cable length, shielded 200 m
Rated load voltage DC 24 V
Current consumption from load voltage L+ (without load) 15 mA
Voltage inputs yes
Min. input resistance (voltage range) 100 kOhm
Input voltage ranges 0 V ... +10 V
Operational limit of voltage ranges +/-0.3%
Operational limit of voltage ranges with SFU -
Basic error limit voltage ranges +/-0.2%
Basic error limit voltage ranges with SFU -
Destruction limit voltage max. 30V
Current inputs -
Max. input resistance (current range) -
Input current ranges -
Operational limit of current ranges -
Operational limit of current ranges with SFU -
Basic error limit current ranges -
Radical error limit current ranges with SFU -
Destruction limit current inputs (voltage) -
Destruction limit current inputs (electrical current) -
Resistance inputs -
Resistance ranges -
Operational limit of resistor ranges -
Operational limit of resistor ranges with SFU -
Basic error limit -
Basic error limit with SFU -
Destruction limit resistance inputs -
Resistance thermometer inputs -
Resistance thermometer ranges -
Operational limit of resistance thermometer ranges
