AutomationDirect D2-16ND3-2 16-point discrete input module

Product Description

The AutomationDirect D2-16ND3-2 is a 16-point sinking/sourcing discrete input module for use with DirectLOGIC 205 PLCs. It is a rugged and reliable module that is

designed for use in industrial applications. The module has two isolated commons, which allows for flexible wiring configurations.

Product Features

• 16 sinking/sourcing discrete inputs

• 20-28 VDC input voltage range

• 30 VDC peak voltage

• 19 VDC minimum ON voltage level

• 7 VDC maximum OFF voltage level

• 2.7 kΩ input impedance

• 4 mA @ 24 VDC input current

• 3.5 mA minimum ON current

• 1.5 mA maximum OFF current

• 5 VDC @ 50 mA base power required

• 3 to 9 ms OFF to ON response time

• 3 to 9 ms ON to OFF response time

• Removable D2-16IOCON terminal block

• Logic-side status indicators

• Operating temperature: -40 to 85°C

• Storage temperature: -55 to 125°C

• Dimensions: 4.0 x 2.0 x 4.0 inches

• Weight: 0.23 pounds

Product Benefits

• High reliability

• Easy to install and use

• Affordable

• Made in the USA

Applications

The AutomationDirect D2-16ND3-2 can be used in a wide variety of industrial applications, including:

• Conveyor systems

• Packaging machines

• Material handling systems

• Robotics

• Process control

Ordering Information

The AutomationDirect D2-16ND3-2 can be ordered from AutomationDirect. The part number is D2-16ND3-2.
