D2-09BDC1-1 AUTOMATION DIRECT

The example on the right shows how

to calculate the power budget for the

Do-more PLC system. The examples

are constructed around a single 9-slot

base using the devices shown. It is

recommended you construct a similar

table for your Do-more PLC system.

Follow the steps to the right to determine

your power budget.

Module Placement and

I/O Usage Tables

There are very few I/O module placement

restrictions with the Do-more H2 Series

PLC family. In general, any mix of analog

and discrete module types can be used

in any local or Ethernet remote base.

However, specialty modules can’t be

used in the Ethernet remote base except

for the F2-08SIM. Reference the Module

Placement Restrictions table to the right

for the Do-more H2 Series PLC.

Analog I/O in the Ethernet remote

bases

When using an analog module in an

Ethernet remote base, the analog update

time to the CPU will be asynchronous to

the scan time. Critical analog I/O should

be located in the local base.

I/O point usage

The table to the right indicates the

number of I/O points consumed by each

module. Use this information to ensure

you stay within the maximum I/O count

of the I/O system you have chosen.
