E50S8-1024-3-T-24 AUTONICS

Product Details

The E50S8-1024-3-T-24 is an incremental rotary encoder from Autonics. It has a Ø8mm shaft, a resolution of 1024 pulses per revolution (PPR), and a totem pole output.

The encoder is housed in an IP65-rated enclosure and is suitable for use in a variety of industrial applications.

Product Specifications

• Shaft outer diameter: Ø8mm

• Max. permissible speed: 5000 rpm

• Max. permissible acceleration: 1000 m/s²

• Starting torque: 0.098 N·m (0.07 oz-in)

• Operating voltage: 12-24 VDC

• Power consumption: 10 mA max.

• Output: A, B, Z, totem pole

• Cable length: 3 m (9.8 ft)

• Operating temperature: -10 to 70°C (14 to 158°F)

• Storage temperature: -20 to 80°C (-4 to 176°F)

• Protection rating: IP65

Product Advantages

• High resolution: The E50S8-1024-3-T-24 has a resolution of 1024 PPR, which means that it can provide accurate position information even for slow-moving applications.

• Wide operating range: The encoder can operate at speeds of up to 5000 rpm and has a wide operating temperature range of -10 to 70°C (-14 to 158°F).

• Rugged construction: The encoder is housed in an IP65-rated enclosure, which makes it resistant to dust and water.

• Easy to install: The encoder comes with a 3 m (9.8 ft) cable, which makes it easy to install.

Product Applications

The E50S8-1024-3-T-24 is a versatile encoder that can be used in a variety of industrial applications, including:

• Conveyor systems

• Packaging machines

• Textile machines

• Printing machines

• Machine tools

• Robotics

Precautions

• Do not exceed the maximum permissible speed or acceleration of the encoder.

• Do not apply excessive force to the shaft of the encoder.

• Do not expose the encoder to extreme temperatures or humidity.

• Do not use the encoder in a hazardous environment.
