H25D-SS-1000-ABC-28V/V-SM20-S BEI

Enclosure Rating IP66 when ordered with shaft seal (on units with an MS connector) or a cable gland (on units with cable

termination).

Temperature

Standard operating temperature -40° C to +85° C;

options available at -40° C to +100° C (Consult factory).

Storage temperature -40° C to +100° C.

Shock 100 g’s for 5 msec duration

Vibration 50 to 2000 Hz @ 30grms

Humidity 98% RH without condensation

• Wide operating temperature range

• Ruggedized, well-sealed unit for long life operation

• Industry standard interfaces make it easy to install

• Extensive electrical protection reduces damage due to miswiring

• High noise immunity especially useful in electrically noisy

automation environments

• Selected configurations available in 1 to 3 days shipment (“Express

Encoder” option)

• Machine control – speed and position

• From wood harvesting all the way to processed lumber

• Oil well logging – wireline and coil tubing

• Agricultural equipment - center point irrigation, planting, harvesting

• Web process control - dancers, slitters, flying knives

• Food processing – inspection stations, conveyor control.

Shaft Diameter 3/8” standard (1/4” as special feature)

Flat On Shaft 3/8” Shaft: 0.75 long X 0.03” deep, 1/4” shaft 0.75 X .02 deep

Shaft Loading 3/8” shaft: Up to 40 pounds axial and 35 pounds radial

Shaft Runout 0.0005 T.I.R. at midpoint regardless of shaft diameter

Starting Torque at 25°C 1.0 in-oz max without shaft seal; 2.5 in-oz max with shaft seal.

Bearings High precision ball bearings, Material: Chrome steel; shielded bearings standard, sealed bearings

optional

Shaft Material Stainless Steel

Bearing Housing Die cast aluminum with protective finish

Cover Die cast aluminum with protective finish

Bearing Life 2 X 108

 revs (1300 hrs at 2500 RPM) at rated load, 1 X 1010 revs (67,000 hrs at 2500 RPM) at

10% of rated load

Maximum RPM 10,000 RPM nominal, 8000 RPM with 1/2” shaft (see Frequency Response, below)

Moment of Inertia 4.1 X 10-4 oz-in-sec2

Weight 13 oz typical
