The new STEP POWER generation of compact power supply units is particularly suitable for installation distributors
and flat control panels thanks to its design. The power supply units are available with 24 V DC output voltage in various
performance classes and widths and with the special voltages 5, 12, 15 and 48 V DC. Their high degree of efficiency and
the low standby losses make for high power efficiency.
Input data
Nominal input voltage 100 V AC ... 240 V AC
AC input voltage range 85 V AC ... 264 V AC
DC input voltage range 95 V DC ... 250 V DC
AC frequency range 45 Hz ... 65 Hz
DC frequency range 0 Hz
Current consumption Approx. 0.28 A (120 V AC)
Approx. 0.13 A (230 V AC)
Inrush surge current < 15 A (typical)
Power failure bypass > 15 ms (120 V AC)
> 90 ms (230 V AC)
Input fuse 1.25 A (slow-blow, internal)
Permissible backup fuse B6
B10
B16
Output data
Nominal output voltage 24 V DC ±1%
Output current 0.5 A (-25°C to +55°C)
0.55 A (-25 °C ... 40 °C permanent)
1 A (maximum output current)
Derating +55°C to 70°C: 2.5% per Kelvin
55 °C ... 70 °C 2.5%/K
Connection in parallel Yes, for redundancy and increased capacity
Connection in series Yes
Control deviation < 1 % (change in load, static 10% ... 90%)
< 2 % (change in load, dynamic 10% ... 90%)
< 0.1 % (change in input voltage ±10%)
Residual ripple < 20 mVPP (20 MHz)
Peak switching voltages nominal load < 30 mVPP (20 MHz)
Maximum power dissipation idling < 0.3 W
Power loss nominal load max. < 2.2 W
General data
Width 18 mm
