• Active power factor correction
• IEC EN61000-3-2 compliance
• Remote sense on main output
• Power fail and remote inhibit
• Single wire current sharing
• Built-in EMI filter
• Adjustable floating 4th output
• 2 Supervisory outputs 5 V and 12 V
• Overvoltage protection
• Overload protection
• Thermal overload protection
• DC power good
• Cover -C
• 120 KHz switching frequency
• Optional with fan cover -CF
• Optional end fan cover -CEF
Input range 85-264 VAC; 120-300 VDC
Frequency 47-440 Hz
Inrush current 20 A max., cold start @ 25°C
Efficiency 75% typical at full load
EMI filter FCC Class B conducted and radiated
CISPR 22 Class B conducted and radiated
EN55022 Class B conducted and
radiated
VDE 0878 PT3 Class B conducted and
radiated.
Power factor 0.99 typical
Safety ground leakage
current <0.5 mA @ 50/60 Hz, 264 VAC input
Output
Maximum power With cover: 250 W with 30 CFM forced
air,
(-C) (-CF) (-CEF).
Adjustment range ±5% min. on main: 5-25 V on 4th output
Supervisory outputs 5 V @ 100 mA regulated, 12 V @ 500
mA
Hold-up time 16 ms @ 250 W load, 115 VAC nominal
line
Overload protection Short circuit protection on all outputs.
Case overload protected @ 110-145%
above peak rating
Overvoltage protection 5 V output: 5.7-6.7 VDC.
Logic Control
Power failure TTL logic signal goes high 50-150 msec
after 5V output. It goes low at least 4
msec before loss of regulation
Remote on/off Requires an external contact (N.O or
N.C) to inhibit outputs
DC-OK TTL logic goes high 50-150 msec after 5
V output. It goes low when there is loss
of regulation.
Remote sense Compensates for 0.5 V lead drop min.
Will operate without remote sense
connected. Reverse connection
protected.
