MOELLER Z00-1.0

Product Description

The Eaton Moeller Z00-1.0 is a thermal overload relay designed to protect motors from overheating. It operates by monitoring the motor's current and tripping when the current exceeds a preset threshold. This prevents

damage to the motor caused by overload conditions such as stalled rotors, locked rotors, or excessive mechanical loads.Product Parameters

• Current rating: 0.6-1.0A



• Trip class: 10

• Mounting: Directly mounted or separately mounted

• Adjustment range: Adjustable

• Contacts: Normally open, normally closed



• Short circuit protection: By fuses or circuit breaker

Product Advantages

• Reliable protection: Accurately monitors motor current to prevent overheating.

• Flexible mounting: Can be mounted directly to the motor or separately.

• Adjustable settings: Allows for customization to specific motor requirements.

• Long service life: Durable construction ensures reliable operation.

• Easy to install: Simple to install and configure.

Precautions

• Correct sizing: Ensure the relay is correctly sized for the motor being protected.

• Proper installation: Follow the manufacturer's instructions for correct installation.

• Regular inspection: Periodically inspect the relay for signs of wear or damage.

• Environmental conditions: Avoid exposing the relay to excessive heat, humidity, or vibration.

Applications

The Moeller Z00-1.0 is suitable for a wide range of applications, including:

• Industrial machinery: Protection of motors in industrial equipment such as pumps, fans, and conveyors.

• Commercial equipment: Protection of motors in commercial appliances and HVAC systems.

• Residential applications: Protection of motors in home appliances and HVAC systems.

Additional Information

• Technical documentation: Detailed technical documentation is available on the Eaton Moeller website.

• Product selection: Use the Eaton Moeller product selection tool to find the right overload relay for your application.

• Support: Contact Eaton Moeller for technical or sales support.

Note: This information is intended for general knowledge and informational purposes only, and does not constitute professional advice. Always consult the product documentation and seek advice from a qualified

 electrician before installing or using this product.
