MOELLER Z00-1.6

Product Description

The MOELLER Z00-1.6 is a thermal overload relay designed to protect electrical motors from damage caused by overcurrent conditions. It operates on the principle of bimetallic strips that heat up in response to excessive

current, causing the relay to trip and disconnect the motor. This prevents overheating and potential fires.

Product Specifications

• Current Rating: 0.4-0.6A

• Trip Class: Various trip classes available to suit different motor types and applications

• Mounting: DIN rail or panel mounting

• Voltage: AC/DC (specific voltage ratings vary by model)

• Trip Characteristics: Adjustable trip characteristics for precise protection

• Auxiliary Contacts: Optional auxiliary contacts for signaling or control purposes

• Enclosure: Various enclosure types for different environmental conditions

Product Advantages

• Reliable Protection: Provides dependable protection for motors against overloads and short circuits.

• Adjustable Trip Characteristics: Allows for customization to match specific motor requirements.



• Compact Design: Saves space in control panels.

• Easy Installation: Simple to install and wire.

• Long Service Life: Built with high-quality components for long-term durability.

• Wide Range of Applications: Suitable for a variety of industrial and commercial applications.

Precautions

• Correct Sizing: Ensure that the relay is correctly sized for the motor's full-load current.

• Proper Wiring: Connect the relay according to the manufacturer's instructions.

• Environmental Conditions: Consider the operating environment, including temperature, humidity, and vibration, when selecting the relay.

• Maintenance: Periodic inspection and maintenance are recommended to ensure optimal performance.

Applications

• Motor Protection: Widely used in industrial machinery, HVAC systems, pumps, fans, and other equipment with electric motors.

• Overload Protection: Protects electrical circuits and equipment from excessive current.

• Phase Failure Protection: Can be configured to detect phase failures.

Additional Information

• Technical Documentation: Refer to the manufacturer's technical documentation for detailed specifications and installation guidelines.

• Compatibility: Ensure compatibility with other components in your electrical system.

• Certification: Check for relevant certifications and approvals (e.g., UL, CE).

Note: For the most accurate and up-to-date information, please consult the official product datasheet from Eaton Moeller.
