MOELLER Z00-1

Product Overview

The Moeller Z00-1 is a thermal overload relay designed to protect electrical motors from overheating. It operates on the principle of bimetallism, where a bimetallic strip heats up in proportion to the motor current. When the current exceeds a preset value, the bimetallic strip bends, causing the relay to trip and disconnect the motor from the power supply.

Key Features and Specifications

• Nominal current range: 0.6 to 1.0 A



• Trip class: 10 (very short tripping time)

• Voltage: Up to 600 V AC

• Mounting: DIN rail or panel mounting

• Phase-failure sensitivity: According to IEC/EN 60 947

• UL listed and CSA certified

Advantages

• Reliable overload protection: Prevents motor damage caused by overcurrent conditions.

• Quick tripping: The trip class 10 ensures rapid response to overload conditions.

• Compact design: Easy to install and integrate into electrical panels.

• Versatility: Suitable for a wide range of applications.

• High quality: Manufactured by Eaton, a leading provider of electrical products.

Precautions

• Proper sizing: The relay must be selected based on the motor's full-load current and operating conditions.

• Installation: Follow the manufacturer's instructions for proper installation.

• Maintenance: Periodic inspection and maintenance are required to ensure optimal performance.

• Environmental conditions: The relay should be installed in a suitable environment, avoiding excessive heat, humidity, or vibration.

Applications

• Industrial machinery: Protection of motors in pumps, fans, conveyors, and other industrial equipment.

• Commercial equipment: Protection of motors in HVAC systems, refrigeration units, and other commercial applications.

• Residential applications: Protection of motors in home appliances and power tools.

Technical Documentation

For more detailed information, please refer to the following technical documentation:

Additional Notes

• Compatibility: Ensure that the Z00-1 is compatible with your specific application and electrical system.

• Replacement: When replacing a Z00-1, always use an identical or equivalent model.

• Safety: Always follow safety procedures when working with electrical equipment.
