The following tables provide the specifications for the F2-08DA-2 Analog Output
Module. Review these specifications to make sure the module meets your
application requirements.
The F2-08DA-2 Analog Output moduleprovides several hardware features:
Supports DL230,DL240,DL250-1and DL260 CPUs (see firmwarerequirements below).
Analog outputs are opticallyisolated from the PLC logic.The module has a removableterminal block, so the module canbe easily removed or changedwithout disconnecting the wiring
Can update all channels in onescan(DL240,DL250-1 and DL260only) .
Outputs are voltage sourcing.Outputs can be configured foreither of these ranges:1) 0 to 5 VDC
2) 0 to 10 VDC
Firmware Requirements:
To use this module, DL230 CPUs musthave firmware version 2.7 orlater. To usethe pointer method of writing valuesDL240 CPUs require firmware version3.0 or later and DL250 CPUs requirefirmware version 1.33 or later.
The F2-08DA-2 analog output requires 16 discrete output points. The module can
be installed in any slot of a DL205 system, but the available power budget and
discrete I/O points can be limiting factors. Check the user manual for your particular
model of CPU and I/O base for more information regarding power budget and
number of local, local expanison or remote I/O points.
