< Adjustable background suppression
< Visible red light
< Sturdy plastic housing
< Optical surface made of scratch-resistant glass
Detection range 50 ... 500 mm
Detection range min. 50 ... 150 mm
Detection range max. 50 ... 500 mm
Light source LED
Light type modulated visible red light
Black-white difference (6 %/90 %) < 5 %
Diameter of the light spot 12 mm at 500 mm sensor range
Opening angle 1.5 °
Ambient light limit 12000 Lux
Functional safety related parameters
MTTFd 540 a
Mission Time (TM) 20 a
Diagnostic Coverage (DC) 60 %
Indicators/operating means
Function indicator LED yellow, lights up with receiver lit
Control elements Programming switch for light/dark switching
Control elements Sensing range adjuster
Electrical specifications
Operating voltage UB 10 ... 30 V DC
Ripple 10 %
No-load supply current I0 100 mA
Output
Switching type light/dark on
Signal output 2 PNP, complementary, short-circuit protected, reverse polarity protected
Switching voltage 30 V DC
Switching current max. 200 mA
Switching frequency f 70 Hz
Response time 5 ms
Conformity
Product standard EN 60947-5-2
Approvals and certificates
EAC conformity TR CU 020/2011
UL approval cULus
CCC approval CCC approval / marking not required for products rated ≤36 V
Ambient conditions
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Storage temperature -20 ... 75 °C (-4 ... 167 °F)
Mechanical specifications
Housing width 26.8 mm
Housing height 91 mm
Housing depth 67.6 mm
Degree of protection IP65
Connection 4-pin, M12 x 1 connector
Material
Housing Terluran® GV15
Optical face glass
Mass 180 g
Background suppression sensor RL23-8-H-500-RT/47/92
2
Germany: +49 621 776 1111 Pepperl+Fuchs Group
Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
