ROCKWELL NX-X16D

Assembly kit for 756 Series IP67 cable assemblies and pluggable connectors with hex nut, consists of:

• Tool kit

• Torque screwdriver with adjustable torque (window scale)

• Adjustment tool for changing the torque

• Socket wrench SW9 (for M8 cable assemblies)

• Socket wrench SW13 (for M12 cable assemblies)

A torque specification of 0.6 Nm for M8 connectors and 1.0 Nm for M12 connectors is required for 756 Series cables and connectors.

M12 plug, A coded, straight, spring clamp technology CANopen/DeviceNet 756-9207/060-000 1

M12 plug, B coded, straight, spring clamp technology PROFIBUS 756-9401/060-000 1

M12 plug, B coded, straight, screw clamp connection PROFIBUS/S-Bus 756-9411/060-000 1

M12 plug, D coded, straight, spring clamp technology ETHERNET/PROFINET 756-9501/060-000 1

M12 plug, right angle, shielded Item No. Pack. Unit

M12 plug, A coded, right angle, spring clamp technology CANopen/DeviceNet 756-9211/060-000 1

M12 plug, B coded, right angle, spring clamp technology PROFIBUS 756-9403/060-000 1

M12 plug, B coded, right angle, screw clamp connection PROFIBUS/S-Bus 756-9413/060-000 1

M12 plug, D coded, right angle, spring clamp technology ETHERNET/PROFINET 756-9501/040-000 1

M12 socket, straight, shielded Item No. Pack. Unit

M12 socket, A coded, straight, spring clamp technology CANopen/DeviceNet 756-9208/060-000 1

M12 socket, B coded, straight, spring clamp technology PROFIBUS 756-9402/060-000 1

M12 socket, B coded, straight, screw clamp connection PROFIBUS/S-Bus 756-9412/060-000 1
