Traco Power TMP30124C

Ultra compact, low profile plastic casing

Fully encapsulated (pollution/dust)

Single-, dual- and triple output models

2 standard package versions:

- Screw terminal block for chassis mount

- Solder pins for direct PCB mount

- Optional pin-connector on request

DIN-rail mount adaptor (optional)

Universal input 85-264 VAC, 47-440 Hz

Protection class ll

 IEC/EN/UL 62368-1 approval, CB-report

Over-temperature protection

 Protection against short circuit

and oveload

3-year product warranty

The TMP & TMPM series AC/DC Power Modules is a new range of fully encapsulated

power supplies in an ultra-compact casing. They feature easy chassis mounting with

screw terminal block connection or direct PCB mounting with solder pins.

Full compliance with International safety standards for industrial control equipment

qualifies the products for worldwide markets.

These power supplies offer a cost effective solution for many space critical applications in commercial and industrial electronic equipment and for polluted and dusty

environment

Voltage set accuracy ±2 % max.

Regulation – Input variation Output 1 1 % max.

– Input variation Output 2/3 3 % max.

– Load variation TMPM 04103 model (0–100%): 1.5 % max.

single and floating outputs (10–100%): 1 % max. (0–100% for TMPM 04 models)

 common ground outputs balanced load (10–100%): 2.5 % max.

 common ground outputs unbalanced load (20/90%): 5.0 % max.

Minimum load TMPM 04 single and sym.dual models: not required

 TMPM 04 asym. dual models: 25% per output

 single and dual output models: 10 % of rated max. current

 triple output models main output: 10 % of rated max. current

 triple output models auxiliary outputs: 20 % of rated max. current

 operation at lower load condition will not

damage these power supplies, however, they

may not meet all listed specifications.

Ripple and noise (20MHz bandwidth) 3.3 VDC & 5.0 VDC outputs: 1.8 % of Vout [mVp-p]

 other outputs: 1.0 % of Vout [mVp-p]

Overload protection by current limit 105 % min. of Inom, fold back, automatic

recovery (long term overload condition may

cause damage to the power supply)

Overvoltage protection by Zener diode (main output only) 120 % of Vout typ.

Start-up time 400 ms typ.

Hold-up time 20 ms typ.
