The RS-485 Modbus version communicates by Modbus RTU, Modbus ASCII, and Levelmaster protocols.
8 data bits, 1 start bit, 1 stop bit, and software selectable parity.
Baud Rate 1200, 2400, 4800, 9600 (default), and 19200 bits/s
Address Range 1 to 255 (default device address is 246)
HART communication is used for configuration via the HART terminals or tunneling via the RS-485.
External power supply
The input voltage Ui
for Modbus is 8-30 Vdc (max. rating).
Note
Rosemount 5300 Level Transmitters with Flameproof/Explosion-proof output have a built-in barrier; no external barrier
needed.(9)
Power consumption
■ < 0.5 W (with HART address=1)
■ < 1.2 W (incl. four HART slaves)
Note
The Rosemount 5300 Level Transmitter with Modbus protocol is configured to HART address 1 at factory. This reduces
power consumption by locking the analog output at 4 mA.
Display and configuration
Integral display
The integral digital display can toggle between: level, distance, volume, internal temperature, interface distance,
interface level, peak amplitudes, interface thickness, percentage of range, analog current out.
Note
The display cannot be used for configuration purposes.
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
