Configure TCP/IP settings in the CLI

1. Log on to the CLI. See “Log on to the CLI” on page 13.

2. Contact your network administrator to obtain the IP address, subnet mask, and default gateway

for the Rack ATS.

3. Use these three commands to configure network settings. (Text in italics indicates a variable.)

tcpip -i yourIPaddress

tcpip -s yourSubnetMask

tcpip -g yourDefaultGateway

For each variable, type a numeric value that has the format xxx.xxx.xxx.xxx. For

example, to set a system IP address of 156.205.14.141, type the following command and

press ENTER:

tcpip -i 156.205.14.141

4. Type exit, and then press ENTER. The Rack ATS restarts to apply the changes.

Network Management with Other Applications

These applications and utilities work with a Rack ATS that is connected to the network.

• PowerNet Management Information Base (MIB) with a standard MIB browser — Perform SNMP

SETs and GETs and use SNMP traps

• StruxureWare Data Center Expert — Provide enterprise-level power management and

management of agents, Rack ATSs, and environmental monitors.

• Device IP Configuration Utility — Configure the basic settings of one or more Rack ATSs over the

network (see “Device IP Configuration Utility”).

• Security Wizard — Create components needed to help with security for the Rack ATSs when you

are using Secure Sockets Layer (SSL) and related protocols and encryption routines.

Recover from a Lost Password

You can use a local computer (a computer that connects to the Rack ATS through the serial port) to access the

command line interface.

1. Select a serial port at the local computer, and disable any service that uses that port.

2. Connect the serial cable (Schneider Electric part number 940-0144A) to the selected port on the

computer and to the Serial port on the Rack ATS.

3. Run a terminal program (such as HyperTerminal®) and configure the selected port for 9600 bps,

8 data bits, no parity, 1 stop bit, and no flow control.

4. Press ENTER up to 3 times to display the User Name prompt. If you are unable to display the User

Name prompt, verify the following:

– The serial port is not in use by another application.

– The terminal settings are correct as specified in step 3.

– The correct cable is being used as specified in step 2.

5. Press the Reset button. The Status LED will flash alternately orange and green within 5 to 7

seconds of pressing the Reset button. When the LED begins flashing, immediately press the

Reset button a second time to temporarily reset the user name and password to their defaults.

6. Press ENTER, repeatedly if necessary, to display the User Name prompt again, then use apc, for

the user name and password. (If you take longer than 30 seconds to log on after the User Name

prompt is re-displayed, you must repeat step 5 and log on again.)
