140CPU65160C SCHNEIDER

Brand: Schneider

Model number:140CPU65160C

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.40kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

140CPU65160C   SCHNEIDER

INQUIRE NOW

Products Name: 140CPU65160C SCHNEIDER

PRODUCT DESCRIPTION

The change of setting groups is only possible if there are no protection or automation functions running (except the thermal overload function). During the autorecloser cycle, if the relay receives an order to change setting groups, this order is kept in memory, and will only be executed after the timer has elapsed.

Description:

Overload Relays

Thermal overload relays sense motor current by

converting this current to heat in a resistance

element. The heat generated is used to open a

normally closed contact in series with a starter

coil causing the motor to be disconnected from

the line.

In spite of being relatively simple and inexpensive,

thermal overload relays are very effective in

providing motor running overcurrent protection.

This is possible because the most vulnerable part

of most motors is the winding insulation and this

insulation is very susceptible to damage by

excessively high temperature.

Being a thermal model of a motor, the thermal

overload relay will produce a shorter trip time at a

higher current similar to the way a motor will reach

its temperature limit in a shorter time at a higher

current. Similarly, in a high ambient temperature,

a thermal overload relay will trip at a lower current

or vice versa allowing the motor to be used to its

maximum capacity in its particular ambient

temperature (if the motor and the overload are in

the same ambient).

Once tripped, the thermal overload relay will not

reset until it has cooled, automatically allowing the

motor to cool before it can be re-started.

Square D manufactures two basic types of

thermal overload relays, the melting alloy and the

bimetallic. In some types, the bimetallic is

available in both non-compensated and ambient

temperature-compensated versions. In both

melting alloy and bimetallic, single element and

three element overloads are available.

Motor Logic Solid State overload relays use an

electronic method of detection, which responds

directly to the motor current. When tripped the

overload relay may be reset either manually or

remotely using the Remote Reset Module. The

Solid State overload relay provides overload

protection only for three phase motors rated up to

600 volts AC.

The Solid State overload relay provides protection

for phase loss and phase unbalance. In addition,

this overload relay is ambient i
