140XTS00200 SCHNEIDER

Brand: Schneider

Model number: 140XTS00200

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.40kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

140XTS00200   SCHNEIDER

INQUIRE NOW

Products Name: 140XTS00200 SCHNEIDER

PRODUCT DESCRIPTION

The protection element also provides a non-sensitive area to avoid instability due to small  asymmetries and unbalances that can generally be present in the network system. This  condition is represented by the characteristic reproduced below, where the hatched area is the tripping zone.

Description:

Motor Branch Circuit Design

Minimum safety provisions for the control of

motors are set forth in the National Electrical

Code. Although these minimum provisions must

be met, they are no substitutes for an intelligent

selection of protective devices made on the basis

of the motor circuit being designed. The code

recognizes this fact in Article 430, Section D,

“Where maximum branch-circuit protective device

ratings are shown in the manufacturer’s overload

relay table for use with a motor controller or are

otherwise marked on the equipment, they shall

not be exceeded even if higher values are allowed

(by the code).”

Square D furnishes an instruction sheet with

every starter. Each instruction sheet includes

thermal unit selections and either fuse or circuit

breaker selections, or both as applicable.

The capability of industrial systems to deliver high

short circuit currents has been increasing steadily

over the years. This fact has caused much

concern about the capability of motor controllers

to withstand high current faults, without creating

hazards for personnel and destruction of

equipment. NEMA standards require that

contactors be able to interrupt currents up to 10

times full load current. Therefore, it is acceptable

for the overload relay to respond before the shortcircuit protector up to this level. At currents above

10 times motor full load current the short circuit

protective device must respond first to minimize

equipment damage. A fully coordinated system is

achieved when the overload relays operate in

response to motor overloads before the fuses or

circuit breaker, and the fuses or circuit breaker

open the circuit before the overload relays trip or

burn out on short-circuit currents.

Proper coordination requires a thorough

knowledge of the time versus current limits of all

of the branch circuit components as well as the

time versus current trip characteristics of the

overload relay and short circuit protective device.


A9F74210   SCHNEIDER

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
