170ENT11002 SCHNEIDER

Brand: Schneider

Model number:170ENT11002

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.40kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

170ENT11002    SCHNEIDER

INQUIRE NOW

Products Name: 170ENT11002 SCHNEIDER

PRODUCT DESCRIPTION

Do not open the secondary circuit of a live CT since the high voltage produced may be lethal to personnel and could damage insulation. Generally, for safety,the secondary of the line CT must be shorted before opening any connections to it.

Description:

Status relay, unlocking

The R1 status relay is energized when the drive power is applied with no fault detected. It de-energizes in the event of a detected fault or

when the drive power is removed.

The drive is reset after a detected fault:

• by switching off the drive until the display disappears completely, then switching on again

• automatically in the cases described in the "automatic restart" function, FLt- menu, Automatic restart Atr page 91 set to YES

• via a logic input when this input is assigned to the "drive reset" function, FLt- menu, Detected fault reset assignment rSF page

91 set to LpH.

Drive thermal detection

Thermal detection is provided by a built-in PTC probe in the power module.

Drive ventilation

Ratings up to 0.75 kW (1 HP) do not include a fan. The fan runs only when the drive thermal state requires ventilation.

Motor thermal detection

Function:

Thermal detection by calculating the I2t.

Note: The motor thermal state memory returns to zero when the drive power is cycled if Motor thermal state memo MtM page 94

is not set to YES.

NOTICE

RISK OF DAMAGE TO THE MOTOR

The use of external overload protection is required under the following conditions:

• Repowering up the product since there is no motor thermal state memory.

• Running multiple motors

• Running motors rated at less than 20% of the nominal drive current

• Using motor switching

Failure to follow these instructions can result in equipment damage.

NOTICE

MOTOR OVERHEATING

• This drive does not provide direct thermal protection for the motor.

• Use of a thermal sensor in the motor may be required for protection at all speeds or loading conditions.

• Consult the motor manufacturer for the thermal capability of the motor when operated over the desired speed range

Failure to follow these instructions can result in equipment damage.
