This LED identifies overload and warning conditions for the ATS. For more information on warning conditions,
see “Configure warning thresholds” on page 71.
Network Status LED
This LED indicates the network status.
10/100 Status LED
This LED indicates the network status of the Rack ATS.
Condition Description
Green The Rack ATS current is below the Near Overload Warning threshold.
Yellow The Rack ATS current is above the Near Overload Warning threshold.
Red The Rack ATS current is above the Overload Alarm threshold.
Condition Description
Off The device that connects the Rack ATS to the network is off or not operating
correctly.
Flashing Green The Rack ATS is receiving data packets from the network at 10 Megabits per
second (Mbps).
Flashing Orange The Rack ATS is receiving data packets from the network at 100 Megabits per
second (Mbps).
Solid Green or Orange The Rack ATS is receiving no network traffic.
Condition Description
Off The Rack ATS is connected to an unknown network.
Solid green The Rack ATS has valid TCP/IP settings.
Flashing green The Rack ATS does not have valid TCP/IP settings.1
Solid orange A hardware failure has been detected in the Rack ATS.
Flashing orange The Rack ATS is making BOOTP requests.
Flashing Orange and
Green (alternating)
The Rack ATS is making DHCP requests.
1 If you do not use a BOOTP or DHCP server, see “TCP/IP Configuration Methods” on page 5 for more
options.
