AS-8534-000 SCHNEIDER

Brand: Schneider

Model number:  AS-8534-000

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.40kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

AS-8534-000   SCHNEIDER   Input module

INQUIRE NOW

Products Name: AS-8534-000 SCHNEIDER

PRODUCT DESCRIPTION

As soon as a phase threshold is running, the instantaneous output associated with this threshold is activated. This output indicates that the protection element has detected a phase fault and that the time delay associated with the threshold has started.

Description:

Supported RADIUS servers

FreeRADIUS and Microsoft IAS 2003 are supported. Other commonly available RADIUS applications may

work but have not been fully tested.

Configure firewalls

Path: Configuration > Security > Firewall > Configuration

Enable or disable the firewall functionality. The configured policy is listed by default. Select the Enable check

box to enable the firewall. The check box is un-checked by default.

• Click Apply to confirm a firewall policy you have selected to enable. The Firewall Confirmation

page will open.

– The Confirmation page contains a recommendation to test the firewall before enabling. It is not

mandatory.

– The first hyperlink goes to the Firewall Policy page.

– The second hyperlink goes to the Firewall Test page.

– Click on Apply to enable the firewall and return to the Configuration page.

– Click on Cancel to return to the Configuration page without enabling the Firewall.

• Click Cancel: No new selection will be enabled. You stay on the Configuration page.

Path: Configuration > Security > Firewall > Active Policy

Select an active policy from the Available Policies drop-down list, and view the validity of that policy.

The current active policy is displayed by default; you can select another from the list.

• Click Apply to enable your changes. If a different firewall was selected and enabled, the change

is effective immediately. If a newly configured firewall policy has been selected, it is

recommended that you test the new firewall before enabling it. (See Configuration above.)

• Click Cancel to restore the original active policy and stay on the Active Policy page.

Path: Configuration > Security > Firewall > Active Rules

When a firewall is enabled, this read-only page lists the individual rules that are being enforced by a current

active policy. See the Create/Edit Policy section for descriptions of the fields (Priority, Destination, Source,

Protocol, Action, and Log).

Path: Configuration > Security > Firewall > Create/Edit Policy

Create a new policy; delete or edit an existing policy:

NOTE: While deleting an active enabled firewall policy cannot be done, editing a running policy can be done

but is not recommended as changes are applied immediately. Instead, disable the firewall, edit the policy, test

it, and then re-enable the policy.

Create a new policy: Click Add Policy, and type in the file name for the new firewall file. The filename should

have a .fwl file extension. If left without a file extension, .fwl will be appended to the name automatically.

• Click Apply: If the filename is legal, the empty file firewall policy file will be created. It will be

located in the /fwl folder with the other policies on the system.

• Click Cancel to return to the previous page without creating a new firewall file.

AS-8534-000   SCHNEIDER

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
