AS-9000-451 SCHNEIDER

Brand: Schneider

Model number:  AS-9000-451

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.40kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

AS-9000-451   SCHNEIDER    Central control module

INQUIRE NOW

Products Name: AS-9000-451 SCHNEIDER

PRODUCT DESCRIPTION

When setting the relay characteristic/torque angle for the three phase directional overcurrent element, a positive angle setting was specified. This was due to the fact that we consider as polarising voltage, the phase voltage value in quadrature of the current under fault conditions. With directional earth fault protection, the residual current under fault conditions lies at an angle lagging the polarising residual earth fault voltage.

Description:

Access: Super User, Administrator

Description: View the existing RADIUS settings, enable or disable RADIUS authentication, and configure

basic authentication parameters for up to two RADIUS servers.

For a summary of RADIUS server configuration and a list of supported RADIUS servers, see “Configure the

RADIUS server” on page 76.

Additional authentication parameters for RADIUS servers are available at the Web interface of the Rack ATS.

See “Manage remote user settings” on page 75 for more information.

For detailed information about configuring your RADIUS server, see the Security Handbook, available at

www.apc.com.

Parameters:

Example 1: To view the existing RADIUS settings for the Rack ATS, type radius and press ENTER.

apc>radius

E000: Success

Access: Local Only

Primary Server: 0.0.0.0

Primary Server Port: 1812

Primary Server Secret: <Password Hidden>

Primary Server Timeout: 5

Secondary Server: 0.0.0.0

Secondar Server Port: 1812

Secondary Server Secret: <Password Hidden>

Secondary Server Timeout: 5

Error Message: E000, E102

Option Argument Description

-a <local |

radiusLocal |

radius>

Configure RADIUS authentication:

• local—RADIUS is disabled. Local authentication is enabled.

• radiusLocal—RADIUS, then Local Authentication. RADIUS and local

authentication are enabled. Authentication is requested from the RADIUS

server first. If the RADIUS server fails to respond, local authentication is

used.

• radius—RADIUS is enabled. Local authentication is disabled.

-p1

-p2

<server IP> The server name or IP address of the primary or secondary RADIUS server. NOTE: RADIUS servers use port 1812 by default to authenticate users. To

use a different port, add a colon followed by the new port number to the end

of the RADIUS server name or IP address. The Rack ATS supports ports

1812, 5000 to 32768.

-o1

-o2

<server port> The port for the primary or secondary RADIUS sever.

-s1

-s2

<server secret> The shared secret between the primary or secondary RADIUS server and

the Rack ATS.

-t1

-t2

<server

timeout>

The time in seconds that the Rack ATS waits for a response from the

primary or secondary RADIUS server.


AS-384B-000   SCHNEIDER

Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
