As soon as a phase threshold is running, the instantaneous output associated with this threshold is activated. This output indicates that the protection element has detected a phase fault and that the time delay associated with the threshold has started.
Entering String Input from the Keypad
When a user enters string input at a keypad, the following process
occurs:
1. The user presents a valid access card and/or PIN (if a PIN is
required) to the door reader.
2. The controller for this reader accepts the user’s credentials, and the
door unlocks.
3. Within 3 seconds of the door unlocking, the user enters two
consecutive asterisks (**) at the keypad to enter escape sequence
mode.
4. The keypad LED flashes slowly to indicate that it is waiting for
input.
5. The user enters a numeric string of up to 30 characters (not
including the two asterisks), then terminates the string with the
pound sign (#).
For example: **10# or **6986310#
6. The door makes the string available to a PE program via its
KeypadString attribute.
Entry Rules for String Input
The following rules apply when using a keypad connected to a door to
enter string input:
z
After the door unlocks for a valid access, if more than 3 seconds
elapse before the user enters two asterisks, the door exits escape
sequence mode. The user must begin the process for string input
again.
z
If a user enters more than 30 characters (not including the first two
asterisks), the door detects when the 31st digit is entered. The door
then replaces the 30th character with T to indicate Tamper, and
sends the string to its KeypadString attribute (no # is needed).
Subsequent characters entered as part of the string are ignored.
