Home / Products / Schneider / AS-E908-016 SCHNEIDER

AS-E908-016 SCHNEIDER

Brand: Schneider

Model number: AS-E908-016

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.40kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

AS-E908-016   SCHNEIDER

INQUIRE NOW

Products Name: AS-E908-016 SCHNEIDER

PRODUCT DESCRIPTION

When setting the relay characteristic/torque angle for the three phase directional overcurrent element, a positive angle setting was specified. This was due to the fact that we consider as polarising voltage, the phase voltage value in quadrature of the current under fault conditions. With directional earth fault protection, the residual current under fault conditions lies at an angle lagging the polarising residual earth fault voltage.

Description:

General

All tables are based on the operation of the motor

and controller in the same ambient temperature,

40°C (104°F) or less. Always be certain the

correct thermal units are installed in the starter

before operating the motor. Each thermal unit

shall be installed such that its catalog number is

visible. On melting alloy thermal units the ratchet

wheel must engage the pawl assembly.

Selection Procedure

1. Determine motor data:

a. Full load current rating

b. Service factor

NOTE: If motor full load current is not known, a

tentative thermal unit selection could be made,

based on horsepower and voltage. Refer to

Page 22.

2. Motor and controller in same ambient

temperature:

a. All starter classes, except Class 8198:

1. For 1.15 to 1.25 service factor motors use

100% of motor full load current for thermal

unit selection.

2. For 1.0 service factor motors use 90% of

motor full load current for thermal unit

selection.

b. Class 8198 only:

1. For 1.0 service factor motors use 100% of

motor full load current for thermal unit

selection.

2. For 1.15 to 1.25 service factor motors use

110% of motor full load current for thermal

unit selection.

3. Motor and controller in different ambient

temperatures:

a. Multiply motor full load current by the

multiplier in Table A. Use the resultant full

load current for thermal unit selection.

4. Locate proper selection table from index,

Pages 19 and 20.

a. The proper thermal unit number will be found

adjacent, to the right of the range of full load

currents in which the motor full load current

or resultant full load current falls.

5. See Page 21 for calculation of trip current rating.
