This section describes how negative phase sequence overcurrent protection may be applied

in conjunction with standard overcurrent and earth fault protection in order to alleviate some

less common application difficulties.

− Negative phase sequence overcurrent elements give greater sensitivity to resistive

phase-to-phase faults, where phase overcurrent elements may not operate.

− In certain applications, residual current may not be detected by an earth fault relay

due to the system configuration. For example, an earth fault relay applied on the delta

side of a delta-star transformer is unable to detect earth faults on the star side.

However, negative sequence current will be present on both sides of the transformer

for any fault condition, irrespective of the transformer configuration. Therefore, a

negative phase sequence overcurrent element may be employed to provide timedelayed back-up protection for any un-cleared asymmetrical fault.

− Where fuses protect motors on rotating machines, a blown fuse produces a large

amount of negative sequence current. This is a dangerous condition for the motor due

to the heating effects of negative phase sequence current at double frequency. A

negative phase sequence overcurrent element may be applied to provide efficient

back-up protection for dedicated motor protection relays.

− It may also be required to simply set an alarm at the presence of negative phase

sequence currents on the system. Operators are then prompted to investigate the

cause of the unbalance.

The negative phase sequence overcurrent elements have a current pick up settings I2>,

I2>>, I2>>>, and are time delayed in operation by the adjustable timers tI2>, tI2>>, tI2>>>.

2.9.1 I2 Thresholds Setting Guidelines

This protection element includes three thresholds.

The first threshold can be set as DT or IDMT trip delay time.

The curves are the same as for the [50/51], [50N/51N] protection.

The current pick-up threshold (settable in the menu PROTECTION G1/[46] Neg. Seg. OC)

must be set higher than the normal negative phase sequence current due to the normal load

unbalance that is always present on the system. This can be set at the commissioning stage,

making use of the relay measurement function to display the standing negative phase

sequence current, and apply a setting at least 20% above.

Where the negative phase sequence element is required to operate for specific un-cleared

asymmetric faults, a precise threshold setting has to be based on an individual fault analysis

for that particular system due to the complexities involved. However, to ensure operation of

the protection element, the current pick-up setting must be set approximately 20% below the

lowest calculated negative phase sequence fault current for a specific remote fault condition.

The correct setting of the time delay is vital for this protection element. It should be also seen

that this element is applied primarily to provide back-up protection to other protective devices

or to provide an alarm. Therefore, it would be associated with a long delay time.

It must be ensured that the time delay is set longer than the operating time of any other

protective device (at minimum fault level) on the system, which may respond to unbalanced

faults, such as:

− Phase overcurrent protection elements

− Earth fault protection elements

− Broken conductor protection elements

− Negative phase sequence influenced thermal protection elements
