ATV61HD55N4Z SCHNEIDER

This specific counter avoids a frequent operation of a CB in case of frequent intermittent fault. The numbers of shoot can be adjusted from 1 to 100 in the cell “Max cycles nb”, settable in a time period from 10min to 24 hours.

Description:

Because Modicon Quantum Hot Standby with Unity systems deliver fault-tolerant

availability through redundancy, use a Modicon Quantum Hot Standby with Unity

system when downtime cannot be tolerated. Redundancy means that two

backplanes are configured identically.

Validity Note The data and illustrations found in this book are not binding. We reserve the right to

modify our products in line with our policy of continuous product development. The

information in this document is subject to change without notice and should not be

construed as a commitment by Schneider Electric.

Related

Documents

Note: Identical Configurations

A Modicon Quantum Hot Standby with Unity system must have identical

configurations:

identical 140 CPU 671 60s which contain both a CPU and a Copro

identical versions of the EXEC

identical power supplies

identical RIO Heads

identical cabling and cabling systems

identical I/O drops

identical sequential placement on the backplane

Title of Documentation Reference Number

Modicon Quantum Hot Standby with Unity User Manual UNY USE 10710 V20E
