Configure TCP/IP settings with the Wizard: The Device IP Configuration Wizard can discover Rack ATSs

that do not have an IP address assigned. Once discovered, you can configure the IP address settings for the

Network Management Cards (NMCs).You can also search for devices already on the network by entering an IP

range to define the search. The Utility scans the IP addresses in the defined range and discovers Rack ATSs

that already have a DHCP-assigned IP address.

NOTE: For detailed information on the Utility, visit the Knowledge Base on the support page on www.apc.com

and search for FA156064 (the ID of the relevant article).

NOTE: To use the DHCP Option 12 (AOS 5.1.5 or higher), see Knowledge Base ID FA156110.

DHCP and BOOTP configuration

The default TCP/IP configuration setting, DHCP, assumes that a properly configured DHCP server is available

to provide TCP/IP settings to the Rack ATS. You can also configure the setting for BOOTP.

A user configuration (INI) file can function as a BOOTP or DHCP boot file. For more information, see “Create

and import settings with the config file” on page 93.

If neither of these servers is available, see “Device IP Configuration Wizard” on page 5.

BOOTP: For the Rack ATS to use a BOOTP server to configure its TCP/IP settings, it must find a properly

configured RFC951-compliant BOOTP server.

1. In the BOOTPTAB file of the BOOTP server, enter the Rack ATS’s MAC address, IP address,

subnet mask, and default gateway, and, optionally, a bootup file name. Look for the MAC address

on the bottom of the Rack ATS.

2. When the Rack ATS reboots, the BOOTP server provides it with the TCP/IP settings.

– If you specified a bootup file name, the Rack ATS attempts to transfer that file from the

BOOTP server using TFTP or FTP. The Rack ATS assumes all settings specified in the bootup

file.

– If you did not specify a bootup file name, you can configure the other settings of the Rack ATS

remotely through its web interface (see “Web Interface” on page 63) or CLI (see “Remote

access to the CLI” on page 7) The default user name and password are apc for both

interfaces. To create a bootup file, see your BOOTP server documentation.

DHCP: You can use an RFC2131/RFC2132-compliant DHCP server to configure the TCP/IP settings for the

Rack ATS.

1. The Rack ATS sends out a DHCP request that uses the following to identify itself:

– A Vendor Class Identifier (APC by default)

– A Client Identifier (by default, the MAC address of the Rack ATS)

– A User Class Identifier (by default, the identification of the application firmware installed on the

Rack ATS)

– A Host Name (by default, apcXXYYZZ with XXYYZZ being the last six digits of the ATS serial

number). This is known as DHCP Option 12.

2. A properly configured DHCP server responds with a DHCP offer that includes all the settings that

the Rack ATS needs for network communication. The DHCP offer also includes the Vendor

Specific Information option (DHCP option 43). The Rack ATS can be configured to ignore DHCP

offers that do not encapsulate the APC cookie in DHCP option 43 using the following

hexadecimal format. (The Rack ATS does not require this cookie by default.)

Option 43 = 01 04 31 41 50 43

– The first byte (01) is the code.

– The second byte (04) is the length.
