This specific counter avoids a frequent operation of a CB in case of frequent intermittent fault. The numbers of shoot can be adjusted from 1 to 100 in the cell “Max cycles nb”, settable in a time period from 10min to 24 hours.
Overview
In addition to supporting the ISO 7811 ABA (American Banking
Association) standard the magnetic stripe cards, CyberStation now
provides support for custom ABA access cards. The CyberStation
standard ABA card format only reads one field (the Primary Account
Number or PAN) consisting of 19 digits from the card, which is used to
identify the card number. The custom ABA card format expands that
capability (in addition to the card number) to provide support for:
Site code Issue code Manufacturer code
CyberStation provides the user with an interface to specify the
structure of a custom ABA magnetic stripe card.
Custom ABA Card Rules
In order for CyberStation to support custom ABA cards the following
requirements apply:
Continuum ACX series controllers or CX series controllers
connected to AC-1 Plus Door Access modules must be used.
A door can be configured for ABA Format2 or Custom ABA, but not
both. Only one custom ABA format will be supported at a time.
The default mode for parsing a card is fixed length. Installations
not using fixed length cards must indicate that they are using
variable length structures with a special identifier character (V)
described later in this section.
