The Eaton PXK-B16/1N/003-A is a combined residual current device (RCD) and miniature circuit breaker (MCB). This versatile electrical component is designed to protect both people and electrical equipment from the risks associated with electrical faults.
Specifications:
Rated current: 16A
Number of poles: 1 pole + N
Trip characteristic: B (standard overload protection)
Rated residual operating current: 30mA
Applications: Residential and commercial installations, outdoor applications (e.g., construction sites), and industrial settings.
Key Advantages:
Safety: Protects against electric shock by rapidly interrupting the power supply in the event of a fault.
Reliability: Constructed with high-quality materials to ensure long-term performance.
Versatility: Suitable for a wide range of applications, including residential and commercial installations.
Compact design: Easy to install and integrate into electrical systems.
Combined functionality: The RCD and MCB functions are integrated into a single device, reducing the need for multiple components.
Precautions:
Installation: Must be installed by a qualified electrician in accordance with local electrical codes and regulations.
Maintenance: Regular inspection and maintenance are recommended to ensure optimal performance.
Replacement: Always replace with an identical or equivalent component.
Environmental conditions: Avoid exposure to extreme temperatures, humidity, or corrosive environments.
Applications:
Residential: Protection of outlets, lighting circuits, and small appliances.
Commercial: Protection of electrical equipment in offices, shops, and other commercial buildings.
Industrial: Protection of electrical installations in industrial settings, including manufacturing facilities and workshops.
Outdoor: Protection of electrical equipment in outdoor applications, such as construction sites and temporary power supplies.
Additional Notes:
RCD function: The RCD monitors the balance between the incoming and outgoing current. If there is an imbalance (indicating a fault), the RCD trips to disconnect the power supply.
MCB function: The MCB protects the circuit from overload and short-circuit conditions.
B-type characteristic:This trip characteristic provides standard overload protection, suitable for most applications.
Energy limiting class: The PXK-B16/1N/003-A is classified as energy limiting class 3, which means it can effectively limit the energy let-through in the event of a fault.
Want to know more?
If you have any further questions about the Eaton PXK-B16/1N/003-A, feel free to ask. Here are some additional topics we could explore:
Technical drawings and dimensions
Installation instructions
Certification and compliance
Comparison with other similar products
