Product or component type Communication card
Range compatibility Altivar 61
Altivar 71
Altivar 71Q
Altivar 61Q
Communication port protocol Modbus TCP
Product specific application For daisy chain mounting
Connector type 1 RJ45
Transmission rate 100 Mbps
10 Mbps
Physical interface Ethernet 2
Web services Altivar viewer
Ethernet statistics
Altivar chart
IO Scanner
FDR Agent
Data editor
E-mail
Security
Complementary
Exchange mode Half duplex and full duplex
Communication data link LLC : IEEE 802.2
MAC : IEEE 802.3
Communication network type IP conforming to RFC791
Communication transport type UDP
8 connections maximum
TCP conforming to RFC793
Concept Transparent Ready class C20
Web server Embedded
Communication service CiA 402 profile
I/O profile
Communication monitoring can be inhibited, adjustable
Diagnostics (08)
FTP
I/O scanning service can be inhibited
Read device identification (43)
Read holding registers (03)
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
Mar 9, 2020
1Read input registers (04)
Read/write multiple registers (23)
SNMP
TFTP
Write multiple registers (16)
Write single register (06)
Display type 1 LED for 10/100 Mbps (speed)
1 LED for FLT (Ethernet fault)
1 LED for RX (reception)
1 LED for STS (IP address)
1 LED for TX (transmission)
