Schneider ATV630C13N4 Central control module

Product Description

The Schneider Electric ATV630C13N4 is a high-performance variable speed drive (VSD) designed for demanding industrial applications. It belongs to the Altivar Process ATV600 and ATV630 series, renowned for

their robust construction, advanced features, and reliability. This particular model offers a power rating of 130 kW, operating on a voltage range of 380 to 480V AC.

Key Features and Specifications

• Power Rating: 130 kW

• Voltage: 380-480V AC

• IP Rating: IP00

• Built-in Communication: 3 RJ45 ports (Ethernet, 2 serial)

• Control: Integrated control panel for easy operation

• Protection: Overcurrent, overload, undervoltage, and overvoltage protection

• Cooling: Forced air cooling

• Mounting: Wall or panel mounting

• Standards: Complies with relevant industry standards and regulations

Product Advantages

• High Performance: Delivers precise speed and torque control for optimal process efficiency.

• Robust Design: Built to withstand harsh industrial environments.

• Advanced Features: Offers a wide range of features, including built-in PLC functionality, advanced diagnostics, and customizable control algorithms.

• Easy to Use: The user-friendly interface simplifies programming and operation.

• Energy Efficiency: Helps reduce energy consumption and operating costs.

• Communication Flexibility: Supports various communication protocols for seamless integration into industrial networks.

Precautions and Considerations

• Installation: Proper installation and wiring are essential for safe and reliable operation. Refer to the manufacturer's installation manual for detailed instructions.

• Environment: Avoid exposing the drive to excessive heat, humidity, or corrosive environments.

• Maintenance: Regular maintenance, including cleaning and inspection, is recommended to ensure optimal performance and longevity.

• Overload Protection: The drive is equipped with overload protection, but it is important to select the correct motor and load to avoid overloading.

• EMC Compliance: Ensure that the drive is installed in accordance with EMC regulations to minimize electromagnetic interference.

Applications

The ATV630C13N4 is suitable for a wide range of industrial applications, including:

• Pumping: Controlling the flow rate of liquids in various industrial processes.

• Fans: Regulating airflow in HVAC systems and industrial ventilation.

• Conveyors: Controlling the speed and direction of conveyor belts.

• Extrussion: Precise control of material extrusion processes.

• Mixing: Achieving precise mixing ratios in various industrial processes.

Note: To ensure that the ATV630C13N4 is the right choice for your specific application, it is recommended to consult with a Schneider Electric representative or a qualified electrical engineer.
