schneider LC1D098 TeSys D contactor
Share
INQUIRE NOW
Products Name: schneider LC1D098
PRODUCT DESCRIPTION
Product Description
The Schneider Electric LC1D098 is a compact and versatile contactor from the TeSys D series. It's designed for a wide range of industrial applications, offering reliable and efficient control of electrical circuits. The contactor typically features 4 poles with 2 normally open (NO) and 2 normally closed (NC) contacts, providing flexible connection options.
Key Features and Specifications
4-pole configuration: Offers versatility in circuit control.
2NO + 2NC contacts: Provides both make and break functions.
AC-1 operation: Suitable for controlling resistive and inductive loads.
Compact design: Saves space in control panels.
DIN rail mounting: Easy installation.
Various coil voltages: Available to match different control systems.
Screw clamp terminals: Secure connections.
Long mechanical and electrical life: Ensures durability.
Product Advantages
Reliability: Built to withstand harsh industrial environments.
Efficiency: Minimizes energy loss.
Safety: Incorporates features to protect personnel and equipment.
Flexibility: Can be adapted to different applications.
Ease of use: Simple to install and maintain.
Global availability: Supported by a worldwide network of distributors.
Precautions
Correct voltage: Always ensure the coil voltage matches the control circuit voltage.
Load capacity: Do not exceed the rated current and voltage of the contactor.
Mounting:Securely mount the contactor to a DIN rail.
Wiring: Follow proper wiring practices to prevent short circuits and electrical shock.
Maintenance: Periodically inspect the contactor for signs of wear or damage.
Applications
The LC1D098 is commonly used in:
Motor control: Starting, stopping, and reversing motors.
Lighting control: Switching large loads, such as industrial lighting.
Automation systems: Part of control circuits for various industrial processes.
Power distribution: Controlling power distribution in electrical panels.
Additional Information
To obtain the most accurate and up-to-date information on the LC1D098, including specific technical data sheets, dimensional drawings, and ordering information, please refer to the Schneider Electric website or contact your local Schneider Electric representative.
Note: The specific features and specifications of the LC1D098 may vary depending on the coil voltage, mounting type, and other options selected. It's essential to consult the product datasheet for detailed information before selecting and installing this contactor.
Would you like me to provide more information about a specific aspect of the LC1D098, such as its coil voltage options, mounting accessories, or typical applications?
Here are some additional keywords you may find useful for further research:
contactor
relay
electrical control
industrial automation
Schneider Electric
TeSys D
Disclaimer: This information is intended for general knowledge and informational purposes only, and does not constitute professional advice. Always consult with a qualified electrician or engineer before
designing or modifying any electrical system.
