schneider PKZM0-1.6

Product Description

The Schneider PKZM0-1.6 is a compact and versatile motor protection circuit breaker designed to safeguard three-phase motors against overload and short circuit conditions. This device is part of Schneider Electric's comprehensive range of electrical protection components and is widely used in various industrial applications.

Key Features and Benefits

• Thermal Overload Protection: The bi-metallic thermal trip element provides accurate overload protection, preventing motor damage due to excessive current.

• Magnetic Short Circuit Protection: A fixed magnetic trip element ensures rapid tripping in the event of a short circuit, minimizing equipment damage.

• Adjustable Trip Settings: The thermal trip can be adjusted to match the specific motor characteristics, optimizing protection.

• Compact Design: The PKZM0-1.6 has a small footprint, allowing for easy installation in tight spaces.

• Easy Mounting: The device is designed for DIN rail mounting, simplifying installation and maintenance.

• High Reliability: Constructed with high-quality materials, the PKZM0-1.6 offers long-term reliability and durability.

• Global Availability: Schneider Electric's extensive distribution network ensures easy accessibility to this product worldwide.

Technical Specifications

• Rated Current: 1.0-1.6 A

• Rated Voltage: 690 V AC

• Number of Poles: 3

• Trip Characteristics: Thermal-magnetic

• Mounting: DIN rail

• Terminals: Screw terminals

• Standards: IEC 60947

Precautions

• Proper Installation: Ensure the device is installed according to the manufacturer's instructions and applicable electrical codes.

• Rated Current Selection: Select the correct rated current based on the motor's full-load current.

• Environmental Conditions: Consider the operating environment, including temperature, humidity, and pollution, when selecting and installing the device.

• Maintenance: Regular inspection and maintenance are essential to ensure optimal performance and safety.

Applications

The PKZM0-1.6 is suitable for a wide range of applications, including:

• Industrial Machinery: Protection of motors in pumps, fans, conveyors, and other industrial equipment.

• Automation Systems: Used in automated processes to protect motors driving actuators and other components.

• Building Automation: Protection of motors in HVAC systems, lighting controls, and other building automation applications.

Additional Information

For more detailed information, please refer to the product datasheet available on the Schneider Electric website or contact your local Schneider Electric representative.

[Insert link to Schneider Electric product datasheet]

Note: This information is intended for general guidance only and should not be considered a substitute for professional engineering advice. Always consult the product datasheet and applicable standards

 for specific application requirements.
