Main
Product or component type Communication card
Range compatibility Altivar 61
Altivar 71
Altivar 71Q
Altivar 61Q
Communication port protocol Modbus TCP
Product specific application For daisy chain mounting
Connector type 1 RJ45
Transmission rate 100 Mbps
10 Mbps
Physical interface Ethernet 2
Web services Altivar viewer
Ethernet statistics
Altivar chart
IO Scanner
FDR Agent
Data editor
E-mail
Security
Complementary
Exchange mode Half duplex and full duplex
Communication data link LLC : IEEE 802.2
MAC : IEEE 802.3
Communication network type IP conforming to RFC791
Communication transport type UDP
8 connections maximum
TCP conforming to RFC793
Concept Transparent Ready class C20
Web server Embedded
Communication service CiA 402 profile
I/O profile
Communication monitoring can be inhibited, adjustable
Diagnostics (08)
FTP
I/O scanning service can be inhibited
Read device identification (43)
Read holding registers (03)
Disclaimer: This documentation is not intended as a substitute for and is not to be used for determining suitability or reliability of these products for specific user applications
Mar 9, 2020
1Read input registers (04)
Read/write multiple registers (23)
SNMP
TFTP
Write multiple registers (16)
Write single register (06)
Display type 1 LED for 10/100 Mbps (speed)
1 LED for FLT (Ethernet fault)
1 LED for RX (reception)
1 LED for STS (IP address)
1 LED for TX (transmission)
Graphic display terminal for control word received
Graphic display terminal for reference received
Web server
Net weight 0.3 kg
Offer Sustainability
EU RoHS Directive Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Mercury free Yes
RoHS exemption information Yes
China RoHS Regulation China RoHS declaration
Contractual warranty
Warranty 18 months
