Schneider W67SCSX-1

Product Overview

The Schneider W67SCSX-1 is an electromechanical relay designed for switching applications in various industrial and commercial environments. It features a compact and rugged construction, making it suitable for demanding applications. The relay offers a DPDT (Double Pole Double Throw) switching configuration, providing two independent switching circuits within a single unit.

Key Features

• DPDT Switching Configuration: The relay offers two independent switching circuits, each with two Form A (Normally Open) and two Form B (Normally Closed) contacts. This versatility allows for a wide range of control applications.

• Compact Design: The relay features a miniature enclosed design, measuring only 18.7mm x 24.8mm, making it ideal for space-constrained applications.

• Rugged Construction: The relay is built to withstand harsh industrial environments, with high-impact resistant housing and durable internal components.

• Coil Options: The relay is available with a variety of coil voltages to suit different power supply requirements, including 9.4VDC, 12VDC, 24VDC, and 48VDC.

• Socket Mount: The relay features a socket mount design for easy installation and removal, allowing for quick maintenance and replacement.

Product Benefits

• Reliable Switching Performance: The relay provides reliable switching performance with high contact switching capacity and extended operational life.

• Space Efficiency: The compact design allows for installation in tight spaces, maximizing space utilization in control panels and enclosures.

• Environmental Durability: The rugged construction ensures the relay can withstand harsh industrial environments, including shock, vibration, and extreme temperatures.

• Versatile Applications: The DPDT switching configuration and various coil voltage options make the relay suitable for a wide range of control applications.

• Easy Installation and Maintenance: The socket mount design facilitates easy installation and removal, simplifying maintenance procedures.

Considerations

• Application Requirements: Carefully evaluate the specific application requirements to ensure the relay's switching capacity, coil voltage, and environmental ratings are suitable for the intended use.

• Load Compatibility: Ensure the connected load does not exceed the relay's contact current and switching voltage ratings to prevent damage to the relay or connected devices.

• Installation Environment: Consider the installation environment and ensure the relay is mounted in a location that protects it from excessive dust, moisture, and extreme temperatures.

• Wiring and Connections: Follow proper wiring practices and ensure all connections are secure and meet electrical safety standards.

Product Applications

• Industrial Automation: The relay can be used for switching control signals in various industrial automation applications, including motor control, valve actuation, and alarm systems.

• HVAC and Building Control: The relay can be employed in HVAC and building control systems to switch lighting circuits, control fans and pumps, and manage temperature regulation.

• Security and Access Control: The relay can be integrated into security and access control systems to control door locks, gates, and alarm triggers.

• Test and Measurement Equipment: The relay can be used in test and measurement equipment to switch signals between different test instruments and devices.

• General Purpose Switching: The relay can be employed for general-purpose switching applications in various electrical and electronic systems.

Overall, the Schneider W67SCSX-1 is a versatile and reliable electromechanical relay well-suited for a wide range of switching applications in industrial and commercial environments. Its compact design, rugged construction, and DPDT switching configuration make it a valuable asset for control systems and automation projects.
