Peer to Peer Security Configuration
Enter Code Enter an Authentification Secret for Key Negotiation (ASCII string up
to 32 characters). The factory default value is “itsasecret”.
Note: You must remember the secret that you enter here for later use.
All controllers and Cyberstation workstations that need to
communicate securely MUST be configured with the same secret.
Confirm Code Re-enter the same Authentification Secret as you did in the “Enter
Code” field.
Do not allow
communications
with unsecured
controllers
Select this radio button if this controller will communicate only with
secure peers.
Allow
communications
with unsecured
controllers
Select this radio button if this controller will communicate with
unsecured controllers on the same logical Continuum network.
Network Security Options
No Network
Security
Select this radio button if you do NOT want packets to have either
authentication or encryption. (Default setting)
Authenticate Only Select this radio button if you want to authenticate packets only.
Choosing this option allows you to authenticate Andover Continuum
protocol packets using SHA1.
Authentication and
Encryption
Select this radio button if you want to authenticate and encrypt
packets. Choosing this option allows you to authenticate and encrypt
Andover Continuum protocol packets using SHA1 for authentication
and 3DES for encryption.
Notes: You must remember which Network Security option you choose for
later use. All Network Controllers and Cyberstation workstations
MUST be configured with the same option in order to communicate
securely.
When you configure the Cyberstation workstation for Network
Security you must import the appropriate IPSec Policy file,
TACAuthenticatePolicy.ipsec for Authentication Only or
TACEncryptAndAuthenticatePolicy.ipsec for Authentication and
Encryption.
Web Server Security Options
Do not apply
Security to Web
pages
Select this radio button if you do NOT want to apply security to the
http packets.
