Brand： ABB
Model number：G408-0001
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.28kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
Description
The Ultra SlimPak G408 is a DIN rail mount, DC input signal
conditioner with 1800VDC isolation between input, output and
power. The field configurable input and output offers flexible,
wide ranging capability for DC current and voltage signals.
The input can be configured for any one of 12 voltage ranges from
10mV to 100V or 6 current ranges from 1mA to 100mA (see Table
1). The output is linear to the input and can be set for either 0-
5V, 0-10V, 0-1mA, 0-20mA or 4-20mA (for models G408-0001)
and -5 to +5V or -10 to +10V (for model G408-1001).
Wide ranging, precision zero and span pots allow 50% adjustability
of offset and span turn-down within each of the 18 switch
selectable ranges. For example, the 0-2mA input range could be
turned down to 0-1mA and provide a full scale output signal (e.g.
4-20mA), or turned down and offset to achieve a 1-2mA/4-20mA
I/O combination.
The G408 also accepts bipolar inputs (e.g. 10V range set to bipolar =
-10 to +10V) and offers selectable normal or reverse operation (e.g.
4-20mA/20-4mA). The ASIC based I/O channel is optically isolated
to 1800VDC and is transformer isolated from the power supply.
Application
The G408 is useful in eliminating ground loops, converting signal
levels, and providing signal drive. The field configurable, wide
ranging capability ensures maximum flexibility for most DC to DC
applications, minimizing spare part requirements.
Diagnostic LED
The G408 is equipped with a dual function LED signal monitor. The
green, front mounted LED indicates both DC power and input
signal status. Active DC power is indicated by an illuminated LED.
If the input signal is more than 110% of the full scale range, the LED
will flash at 8Hz. Below -10%, the flash rate is 4Hz.
