Brand: WoodWard
Model number:1753-12E6U2B2S1
Colour:new
Warranty: 12 months
Lead Time:3-day working day
Country of origin: USA Price: Please contact us
Product weight:1.82kg
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
1753-12E6U2B2S1 Woodward Digital Input Module
INQUIRE NOW
Products Name: 1753-12E6U2B2S1 Woodward
PRODUCT DESCRIPTION
Do not tin (add solder to) the wires that terminate at the EGCP-2
terminal blocks. The spring-loaded CageClamp terminal blocks are
designed to flatten stranded wire, and if those strands are tinned
together, the connection loses surface area and is degraded.
Grounding for Protection Against Electric Shock
Protective Earth (PE) must be connected to the termination point on the backside of the unit next to the
label with the symbol (or 1 of 3 other like termination points without label) to reduce the risk of electric
shock. The EGCP-2 ships with 2 thread forming screws (M4 x 6 mm, Woodward #1029-525) for this
connection. The conductor providing the connection must have a properly sized ring lug and wire larger
than or equal to 3.0 mm² (12 AWG).
Recommended Grounding Practices
Providing the proper ground for the EGCP-2 is important. Improper connection of the EGCP-2 chassis to
the ground plane may lead to stray currents between the reference point for the AC signal sources
(current and voltage transformers), and the reference point for the sensing inputs on the EGCP-2.
Differences in potential between these two points results in equalizing current flow which then produces
unacceptably high common mode voltages. Common mode voltages may result in improper readings for
the sensed AC inputs, or even damage to the EGCP-2 product in extreme cases. To minimize this
problem, it is necessary to provide a low resistance path between the AC signal reference point, and the
chassis of the EGCP-2. Typically,this point is the designated ground for the generator set and related
instrument transformers.
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online serviceRelated products:
