5441-419 WOODWARD

Brand:  WoodWard

Model number:5441-419

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.85kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

5441-419   WOODWARD

INQUIRE NOW

Products Name: 5441-419 WOODWARD

PRODUCT DESCRIPTION

Woodward has launched hardware and software updates to address many CIP requirements; however, complete NERC/CIP compliance involves more than the controls and is dependent on plant infrastructure and procedures. The physical security remains the user’s responsibility.

Benefits:

Check Failsafe and Actuator Travel:

 Set the signal-generator frequency to about half of idle speed. Set the idlerated switch to rated. Turn the signal generator and governor power on. The

linkage must be at the maximum-fuel position. Except for Detroit Diesel

engines, verify that linkage travel is limited by the prime-mover fuel control,

not by the actuator stop. Turn the signal generator off and remove the

connections at terminals 5 and 6. The linkage should move to the minimum

fuel position. Verify that linkage travel is limited by the prime mover’s fuel

control, not by the actuator stop.

 Preset Rated Speed:

 Set the signal generator for MPU frequency at rated speed and connect it to

terminals 5 and 6. Put the idle-rated switch in the rated position. Set the

speed trim pot, if connected, to mid-position. Observe the linkage position.

 If the linkage Is at the maximum fuel position:

 Slowly turn the rated speed pot counterclockwise until the linkage just

begins to move to the minimum fuel position. Start Fuel (if present) must be

adjusted to the maximum clockwise position or the actuator will not move to

maximum.

 If the linkage Is at the minimum fuel position:

 Slowly turn the rated speed pot clockwise until the linkage just begins to

move to the maximum fuel position.

 Continue to adjust the rated speed pot very slowly in the appropriate

direction, trying to stop the linkage between the minimum and maximum fuel

stops. Because it is not possible to stop the motion, cease adjusting when

the linkage moves slowly. The rated speed reference is now set very close

to desired speed. A slight adjustment when the engine is running will

achieve the exact speed.

 Preset Idle Speed:

 Preset idle speed only after presetting rated speed. Set the signal generator

for the MPU frequency at idle speed. Put the idle-rated switch in the idle

position. Observe the linkage position.

 If the linkage is at the maximum fuel position:

 Slowly turn the idle speed pot counterclockwise until the linkage just begins

to move to the minimum fuel position. Start Fuel (if present) must be

adjusted to the maximum clockwise position or the actuator will not move to

maximum.

 If the linkage is at the minimum fuel position:

 Slowly turn the idle speed pot clockwise until the linkage just begins to move

to the maximum fuel position.

 Continue to adjust the idle speed pot very slowly in the appropriate direction,

trying to stop the linkage between the minimum and maximum fuel stops.

Because it is not possible to stop the motion, cease adjusting when the

linkage moves slowly. The idle speed reference is now set very close to

desired speed. A slight adjustment when the engine is running will achieve

the exact speed.
