5461-646 WOODWARD

Brand:  WoodWard

Model number:5461-646

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.85kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

5461-646   WOODWARD

INQUIRE NOW

Products Name: 5461-646 WOODWARD

PRODUCT DESCRIPTION

One side of the secondary of all CTs must be earthed. The earth connection should be made on the side of the secondary facing the protected object. The polarity of the CTs must be in accordance with the following diagram.

Benefits:

Actuator

As shown in Figure 4-2, the actuator is mechanically simple. It has specially

designed rotor and stator shapes which provide reliable, effective performance.

The rotary design gives 35° * shaft rotation to low-mass, low-friction fuel controls.

The magnetic circuit, when powered by the speed control, applies torque in the

increase-fuel direction. Two ** preloaded internal return springs supply shaft

torque in the decrease fuel direction. The preload can be factory reduced to

compensate for some external linkage forces acting in the decrease fuel

direction.

*—For 1712/1724 Actuators, and 30° for 512/524 Actuators.

**—Two springs for 1712/1724 Actuators; one spring for 512/524 Actuators.

Figure 4-2. Actuator Schematic

Applications Using a Ramp Generator

The Ramp Generator slows the speed change between idle and rated speeds. It

has no effect on steady-state speeds. Once set it provides a constant speed

change per second by biasing the speed reference when changing from idle to

rated and vice versa. The accel and decel pots control the rate of change.

Acceleration and deceleration times depend on accel and decel pot settings and

the difference between idle and rated speeds.

Paralleled Generator Applications

A Load Sensor is used with the EPG for isochronous or droop paralleling.

With an isolated bus, isochronous load sharing is usually chosen. In an

isochronous load sharing system, the load gain signal voltage is shared with all

other controls through paralleling lines, and provides an average load gain signal

used by the controller circuits.
