Brand: WoodWard
Model number:5462-236
Colour:new
Warranty: 12 months
Lead Time:3-day working day
Country of origin: USA Price: Please contact us
Product weight:0.85kg
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
5462-236 WOODWARD
INQUIRE NOW
Products Name: 5462-236 WOODWARD
PRODUCT DESCRIPTION
Electromagnetic Interference (EMI) can be an intermittent condition. Improperly shielded installations can provide good control for a while and then cause problems. For this reason it is important to be sure all shields are properly installed.
Benefits:
This chapter covers the checkout and calibration of the SPM-A Synchronizer.
These procedures must be followed in sequence for proper calibration of the
synchronizer. Notes in the text indicate when procedures are different for each
SPM-A model.
Before attempting to calibrate the synchronizer, read Woodward
Manual 82715, Guide for Handling and Protection of Electronic
Controls, Printed Circuit Boards, and Modules.
General Information
Read and follow these instructions carefully when checking or calibrating the
synchronizer:
· Observe precautions for handling static-sensitive devices (see page iii).
· Use battery-operated test equipment whenever possible.
· Isolate the test equipment from all grounds, including the chassis.
· Use a digital multimeter (DMM) for all measurements and a volt-ohmmeter
(VOM) when checking indicators and relay contacts.
· Apply power to the synchronizer before applying power to any test
equipment connected to it.
· Make sure that the wiring connections have been made in accordance with
the plant wiring diagram (Figure 1-4) and that the connections are tight.
· The values given in this procedure are the values used by the factory for
calibration of the new synchronizer. Be sure that no specification changes or
modifications have been made that will change these values.
Pre-Checkout
All other units in the engine control system must be adjusted and working
correctly before operating the synchronizer. While operating the engine to make
adjustments on the other units, the synchronizer mode switch (user supplied)
must be in the OFF position.
Dwell Time Adjustment
The dwell time is factory set at 1/2 second. To set the dwell time for one of the
other settings (1/8, 1/4, or 1 second) do the following:
1. Turn off the power to all voltage inputs to the synchronizer.
2. Remove the four elastic nuts securing the synchronizer cover. Remove the
cover.
To prevent damage to the components of the synchronizer, read and
follow the Electrostatic Discharge Awareness precautions on page iii.
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
