5463-127 WOODWARD

Brand:  WoodWard

Model number:5463-127

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.85kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

5463-127   WOODWARD

INQUIRE NOW

Products Name: 5463-127 WOODWARD

PRODUCT DESCRIPTION

Do NOT use the minimum-fuel contact as a part of any emergency stop sequence. The emergency may be caused by a governor malfunction which would also cause a malfunction of the minimumfuel feature. Use of the minimum-fuel contact for an emergency stop sequence could cause overspeed of the prime mover and mechanical

damage and personal injury, including death.

Benefits:

Even though governor faults cause improper prime mover operation, improper

prime mover operation can be also caused by other items such as low fuel

pressure. When the prime mover stops working properly, find out which part is

defective. Do this by:

1. Substituting, if available, a part that works for the one suspected of causing

the problem.

2. Simplifying the system. Remove options and observe performance after

each removal.

3. Testing the parts suspected of causing the problem. Follow the

manufacturer’s instructions or set up input and operating conditions which

produce known outputs.

To test the EPG, use Chapter 2 to verify that the installation is correct and

perform the installation check. Those checks are the best way to test the EPG.

The Preset Rated Speed section (under Step 6 of the Installation Checks in

Chapter 2) is the best test of the EPG’s ability to control speed. It requires the

use of a signal generator with an isolated output. If appropriate, do the checks for

Paralleled Generator Applications with the Load Sensor (referenced in Chapter 2,

manual 82313).

Other Checks

Do the installation checks described in the previous paragraph first. Then check

the following:

1. If the prime mover is stable at some speeds or power outputs but oscillates

at others, the linkage may not be compatible with the fuel control. Refer to

Linkage Compatibility under Actuator Mounting and Linkage in Chapter 2.

2. If the prime mover oscillates at low frequency (about 1 Hz) and the Gain and

Stability adjustments (in Chapter 2) are correct, then friction in the linkage

may be the cause.

· Disconnect the actuator from the fuel control.

· Manually stroke the fuel control linkage from stop to stop as if the

actuator were moving it. The linkage must move freely without friction

and without backlash. Lubricate or replace linkage or fuel control parts

as required.

3. If the prime mover is unstable only when load sharing, verify that:

· Load sensor CTs and PTs are wired correctly.

· Voltage regulator droop or cross current compensation is set correctly.

· The voltage regulator is not intermittent or otherwise faulty.

 If the problem is still there, reduce the load gain a little and set the load gain

pot on all other load sensors in the system for the same load signal at full

load. It may be necessary to reduce the load signal to 3 volts in extreme

cases. Consult with your authorized Distributor or with Woodward in such

cases.
