5464-210 WOODWARD

Brand:  WoodWard

Model number:5464-210

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.85kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

5464-210   WOODWARD

INQUIRE NOW

Products Name: 5464-210 WOODWARD

PRODUCT DESCRIPTION

Prior to commissioning ensure that all measuring devices are connected in correct phase sequence. The connect command for the unit circuit breaker must bedisconnected at the unit circuit breaker. The field rotation must be monitored for proper rotation. Any absence of or incorrect connection of voltage measuring devices or other signals may lead to malfunctions and damage the unit, the engine, and/or components connected to the unit

Benefits:

The MicroNet 5466-253 and 5466-316 HDCombo modules were first introduced in 1997 for the

Steam Controls market. This module includes a combination of eight Analog Inputs, four Analog

Outputs, four Speed Inputs, and two Proportional Actuator Outputs. The -253 version has an ideal

combination of I/O for TMR and 5009 systems controlling valves with proportional actuators.

Woodward’s newer Speed/Analog combination module (5466-1115) lacks the on-board proportional

actuator capability of the older HDCombo modules, requiring the addition of separate Two-Channel

Actuator modules. This consumes valuable I/O space in the main TMR chassis.

Since 2016, Woodward has been providing HDCombo modules primarily for spare parts and system

upgrades, and has pushed steam and compressor customers to use the 5466-1115 along with

supplementary 2CH Actuator control modules. Woodward’s 5009 standard steam turbine control

was also changed to utilize the newer combo modules.

Updated Product Status

In early 2020, Woodward found an opportunity to allocate key parts shared with other Woodward

controls for use on the HDCombo. Woodward then searched for and procured stock of other

components required to keep this older design in production.

The 5466-253 has been made “Preferred” on Woodward’s system and is now approved for use on

new installations. The 5466-316 remains Non-Preferred, however it can be used for retrofits and

spares.

Here is a table showing the HDCombo modules and their current status and dates:

Part Number Usage FTM Current Status Non-Preferred Inactive

5466-253 TMR 2 x 5501-365 Preferred 2025 2030

5466-316 Simplex 5501-371 Non-Preferred 2017 2030

Note 1: Non-preferred means not intended for new system installations. Unit remains fully

supported for retrofits, spares and repairs.

Note 2: Inactive means that the module can no longer be produced. Typically this is because of

component obsolescence. Repairs and exchange units are supported as long as feasible

(typically 5+ years after inactivation).

Note 3: FTM availability should meet or exceed that of Combo modules.

Note 4: The future dates shown above are approximate based on Woodward’s current

information on component obsolescence and planned component usage rates. The dates cannot

be guaranteed due to the potential for unexpected obsolescence issues to occur.

For installation and usage information, please see Woodward manual 26167.
